Loa JBL SCL 3
Thông Số Kỹ Thuật:
Speaker Type | Two-way In-Wall Loudspeaker |
---|---|
Low Frequency Transducer | Dual 5-¼” (130mm) cast-frame, advanced aluminum matrix cone woofers |
Mid/High Frequency Transducer | D2-derived 1″ (25mm) 2409H annular ring, Teonex® diaphragm compression driver |
Maximum Recommended Amplifier Power | 200 watts RMS |
Frequency Response (-6dB on-axis) | 65 Hz – 33KHz |
Coverage area (-6dB @ 20 KHz) | 90 x 60 deg, (-6dB @ 10 KHz) 110 x 90 deg (Hor. x Vert.) |
Sensitivity (2.83V@1m) | 91dB |
Nominal Impedance | 6 Ohm |
Crossover Frequencies | 1.3 KHz |
Enclosure type | Sealed In-Wall Mount with included back box |
Inputs | Dual Gold-plated Five-way Binding Posts |
Dimensions (H x W x D) | 16.46″ x 16.46″ x 6.01″ (418mm x 418mm x 153mm) |
Weight | 24.3 lb (11.02 kg) |
Finishes | Matte Black |
