Name: Mua Loa JBL SCL 5 Chính Hãng - LH 0983.83.46.46 Giá Tốt Nhất VN
Availability: InStock

Loa JBL SCL 5

Thông Số Kỹ Thuật:

Type	2-Way In-ceiling loudspeaker
Low Frequency Driver	7” (180 mm) advanced Aluminum Matrix cone cast-frame woofer (JW180PB-6)
High Frequency Driver	1″ (25 mm) 2409H Teonex annular ring-diaphragm compression driver
Recommended Amplifier Power	25 – 125W RMS
Impedance	6 Ohm
Loudspeaker Sensitivity	86 dB/2.83V/1m (2pi anechoic)
Frequency Response	48Hz – 32kHz (-6 dB on-axis), 2pi anechoic
Crossover Frequency	1575 Hz
High Frequency Coverage Angle (-6 dB)	60-degree Vertical (Up 30-degree, Down 30-degree, from 45-degree Vertical Center line), 120-degree Horizontal, from 2k Hz to 10k Hz.
Enclosure Type	Open back
Controls	Boundary Proximity Control
Grille Dimensions	Round – 12.5″ (318 mm) diam.
Grille Dimensions	Square – 12.5″ (318 mm) x 12.5″ (318 mm)
Product Dimensions (with grille)	12.5″ H x 12.5″ W x 5.98″ D (318 mm x 318 mm x 151.9 mm)
Cut-out Diameter	11.2″ (285 mm)
Accessory Rough-in Bracket	CB10
Mounting Depth	5.58″ (141.8 mm)
Input Type	Gold-plated spring-loaded binding posts
Product Weight	8.6 lb. (3.9 kg), 9.2 lb. (4.2 kg) with one grille
Shipping Weight	12.5 lb. (5.7 kg)
Shipping Units of Measure	Each
Warranty	5 Years
